Corundum Mullite Castables

Corundum mullite castables (also called corundum mullite refractory castables) are popular refractory castables for furnace application in the lining of significant power station boiler wear linings and other high-temperature furnaces. Corundum mullite castables have good properties of high-temperature endurable ability, good thermal shock resistance and structural peeling resistance, good thermal shock resistance, high softening temperature, low creep rate, and good chemical corrosion resistance, etc.

Introduction of Corundum Mullite Castables

Corundum mullite castables (also called corundum mullite refractory castables) are popular refractory castables for furnace application in the lining of significant power station boiler wear linings and other high-temperature furnaces. Corundum mullite castables have good properties of high-temperature endurable ability, good thermal shock resistance and structural peeling resistance, good thermal shock resistance, high softening temperature, low creep rate, and good chemical corrosion resistance, etc.

Corundum mullite castables’ raw material has brown corundum, white corundum, andalusite, mullite, and high quality bauxite with a specific ratio of ultrafine powder. In industry, mullite is usually artificially synthesized with high purity, dense structure, low creep rate, strong erosion resistance, and well thermal shock resistance.

Corundum mullite castables can perform high properties such as high crushing strength, high-temperature stability, thermal shock resistance, and wear and chemical erosion resistance in the lining of large power station boilers and other high-temperature equipment.

Corundum mullite castables are divided into several grades, products with Al2O3 ≥ 90% based on the corundum phase, products with Al2O3 ≥ 80% based on the corundum phase and mullite phase, and products with Al2O3 ≥ 50% based on the mullite phase. Because corundum mullite castables have the following superior properties in the process of high-temperature use: high-temperature strength, good density modification, good overall structural integrity at high temperatures, good wear resistance, and erosion resistance, It has strong slag corrosion resistance, acid, and alkali corrosion resistance, peeling resistance and no pollution, so it is widely used in electric furnace roof, ladle, garbage incinerator, petrochemical furnace, cement kiln, etc., with good application effect.

Packing of Corundum Mullite Castables

Plastic bag(25kg), Kraft bag (25 kg), Plastic Ton bag(1 ton);

1 ton on the pallet with plastic film & bundle belts.

Per your requests

Application of Corundum Mullite Castables

Widely used in the lining of coal kilns before and after large cement kilns, coal injection pipes, and other industrial kiln linings.

Widely used in large and medium-sized cement kiln mouth, coal injection pipe, kiln head cover, and cooling machine low wall.

Widely used in circulating fluidized bed boilers, metallurgy, petrochemical, thermal power, and other professional fields.

Widely used for the lining of large power station boiler wear linings and other high-temperature furnaces.

Properties of Corundum Mullite Castables

1. The product has high purity, high density, and good compactness.

2. Good wear resistance, erosion resistance, slag corrosion resistance, and thermal shock resistance.

3. High temperature, good performance under high temperature.

Characteristics of Corundum Mullite Castables

  • High strength

  • High-temperature resistance

  • Strong wear resistance

  • Good erosion resistance

  • Excellent thermal shock stability

Chemical & Physical Index

Item XHJCMC-70 XHJCMC-75 XHJCMC-85 XHJCMC-90
Al2O3 % 70 75 85 90
SiO2 % 25 17 13 6
Fe2O3 % 1 1 1 1
Bulk Density g/cm3 2.7 2.8 2.9 3
Cold Crushing Strength Mpa 110℃*24h 95 105 110 110
1100℃*3h 100 110 115 120
1400℃*3h 115 120 125 125
Modules of rupture Mpa 110℃*24h 15 15 15 15
1100℃*3h 16 17 18 19
1400℃*3h 17 18 19 20
Room temperature abrasion loss cm3 <8.5 <7.3 <6.5 <6.5
0.2Mpa refractoriness under load ℃ 1450 1480 1550 1570
Max Service Temp ℃ 1550 1600 1600 1690
Heavy burn line rate(1300℃*3h,%) -0.3 -0.2 -0.2 -0.2
